Multi-Modal Endpoints
Overview
Beyond text-based chat completions, Apinizer AI Gateway supports four additional modalities, plus an alternative endpoint shape for text generation itself:
- Speech to Text (STT) —
/v1/audio/transcriptions - Text to Speech (TTS) —
/v1/audio/speech - Image Generation —
/v1/images/generations - Embeddings —
/v1/embeddings - Responses API —
/v1/responses
All five endpoints use the OpenAI-compatible request/response format; your existing OpenAI SDK clients work without code changes beyond pointing base_url at Apinizer. Every one of them goes through the same gateway pipeline as chat completions — limit plans and the Token Rate Limit policy, cost tracking, and guardrails such as PII masking all apply.
Video is not supported.
Speech to Text (STT)
Transcribes an audio file into text:
from openai import OpenAI
client = OpenAI(
api_key="your-apinizer-credential-key",
base_url="https://your-apinizer-gateway.com/api/ai/v1"
)
with open("recording.mp3", "rb") as audio_file:
transcript = client.audio.transcriptions.create(
model="whisper-1",
file=audio_file
)
print(transcript.text)
- The request is sent as multipart/form-data
- Usage is metered based on audio duration, rather than token count
- The response text can be passed through the existing PII masking policy — personal data detected in the transcript is masked using the same rules as other text endpoints
Text to Speech (TTS)
Converts text into speech; the response is returned as a binary audio stream:
response = client.audio.speech.create(
model="tts-1",
voice="alloy",
input="Hello, this is a test message."
)
response.stream_to_file("output.mp3")
The TTS response is not JSON, but an audio file (binary) returned directly — the gateway passes this response type through transparently, preserving the content type.
Image Generation
Generates an image from a text prompt:
response = client.images.generate(
model="gpt-image-1",
prompt="Sunset over the ocean, digital art",
n=1,
size="1024x1024"
)
print(response.data[0].url)
Embeddings
Converts text into a vector representation — the same interface used by Knowledge Bases, RAG, and the Semantic Cache to store and search content in a Vector Database:
response = client.embeddings.create(
model="text-embedding-3-small",
input="The quick brown fox jumps over the lazy dog."
)
print(response.data[0].embedding)
Usage is metered on input tokens only — an embedding call has no output token cost. Before routing a request, Apinizer checks that the target provider and model can serve embeddings, so a request can't accidentally be sent to a chat-only model. See Provider and Model Checks.
Responses API
/v1/responses is OpenAI's newer, alternative shape for text generation — the same underlying capability as chat completions, with a different request/response envelope: an input field instead of messages[], and an output[] array instead of choices[].
response = client.responses.create(
model="gpt-4o",
input="Tell me a three-sentence bedtime story about a unicorn."
)
print(response.output_text)
Streaming works the same way as chat completions — pass stream=True and consume the returned event stream.
Provider Support
Only OpenAI-native providers speak the Responses API's wire format: OpenAI, Azure OpenAI, and Custom OpenAI-Compatible connections. Routing a Responses request to any other provider (Anthropic, Google Vertex/Gemini, AWS Bedrock, a self-hosted engine, and so on) returns HTTP 400 rather than silently falling back to a chat-shaped translation — several Responses-specific fields have no chat-completions equivalent, so a silent translation could quietly drop part of the request (for example previous_response_id, which carries the conversation state on the provider side).
/v1/responses support in this release covers plain text generation, with the same quota, cost-tracking, and guardrail coverage as Chat Completions. Three things work differently for now:
- Tool calls — a Responses request that results in a function/tool call is returned to the client as-is; the gateway's automatic tool-calling loop (used with the MCP Gateway) currently runs only for Chat Completions requests.
- Text models only — a Responses request routed to an embedding or audio-only model is rejected with HTTP 400.
- Structured-prompt features — Prompt Decorator, Prompt Template, Topic Guard, RAG injection, and the semantic cache's similarity match all read the standard
messages[]array. Since a Responses request carriesinputinstead, Prompt Decorator and Prompt Template currently pass such a request through unaffected, while Topic Guard, RAG, and the semantic cache fall back to scanning the request's raw text rather than parsing it message-by-message.
Pricing and Usage Metrics
The additional modalities are integrated into the existing AI Cost Settings and Reports infrastructure:
| Modality | Pricing Unit | Usage Metric |
|---|---|---|
| STT (whisper) | Per minute | Audio duration (seconds/minutes) |
| TTS | Per character | Input character count |
| Image generation | Per image (by size) | Number of images generated |
| Embeddings | Per 1M input tokens | Input token count |
These metrics are visible in Reports and Analytics alongside other LLM models, broken down by person, team, project, and model.
Set the price of a model (such as whisper, TTS, or gpt-image) in the provider's model drawer, under Cost management. A model without a price counts as 0 in cost reports. See AI Cost Settings.
Endpoint Routing
The gateway automatically recognizes the target path of the incoming request (/v1/chat/completions, /v1/audio/transcriptions, /v1/audio/speech, /v1/images/generations, /v1/embeddings, /v1/responses) and routes it to the modality-specific processing pipeline (including binary response support, multipart parsing, and duration-based usage calculation) — no additional configuration is required, and all modalities can be served through the same AI Gateway.
Provider and Model Checks
Before a request is sent, the gateway checks two things. The provider type must offer the endpoint — a provider without an embeddings, audio or image endpoint cannot serve that request. And when the model has a modality set in the provider's model settings, the modality must fit the endpoint. A mismatch is rejected with HTTP 400, for example a chat-only model on /v1/embeddings, a text or embedding model on the audio endpoints, or an embedding or audio model on /v1/responses. A model with no modality set is not checked.
