Multi-Modal Endpoints

Overview

Beyond text-based chat completions, Apinizer AI Gateway supports four additional modalities, plus an alternative endpoint shape for text generation itself:

• Speech to Text (STT) — /v1/audio/transcriptions
• Text to Speech (TTS) — /v1/audio/speech
• Image Generation — /v1/images/generations
• Embeddings — /v1/embeddings
• Responses API — /v1/responses

All five endpoints use the OpenAI-compatible request/response format; your existing OpenAI SDK clients work without code changes beyond pointing base_url at Apinizer. Every one of them goes through the same gateway pipeline as chat completions — token/USD quotas, cost tracking, and guardrails such as PII masking all apply.

Speech to Text (STT)

Transcribes an audio file into text:

from openai import OpenAI

client = OpenAI(
    api_key="your-apinizer-credential-key",
    base_url="https://your-apinizer-gateway.com/api/ai/v1"
)

with open("recording.mp3", "rb") as audio_file:
    transcript = client.audio.transcriptions.create(
        model="whisper-1",
        file=audio_file
    )

print(transcript.text)

• The request is sent as multipart/form-data
• Usage is metered based on audio duration, rather than token count
• The response text can be passed through the existing PII masking policy — personal data detected in the transcript is masked using the same rules as other text endpoints

Text to Speech (TTS)

Converts text into speech; the response is returned as a binary audio stream:

response = client.audio.speech.create(
    model="tts-1",
    voice="alloy",
    input="Hello, this is a test message."
)

response.stream_to_file("output.mp3")

not

The TTS response is not JSON, but an audio file (binary) returned directly — the gateway passes this response type through transparently, preserving the content type.

Image Generation

Generates an image from a text prompt:

response = client.images.generate(
    model="gpt-image-1",
    prompt="Sunset over the ocean, digital art",
    n=1,
    size="1024x1024"
)

print(response.data[0].url)

Embeddings

Converts text into a vector representation — the same interface used by Knowledge Bases, RAG, and the Semantic Cache to store and search content in a Vector Database:

response = client.embeddings.create(
    model="text-embedding-3-small",
    input="The quick brown fox jumps over the lazy dog."
)

print(response.data[0].embedding)

Usage is metered on input tokens only — an embedding call has no output token cost. Before routing a request, Apinizer checks that the target model actually supports embeddings, so a request can't accidentally be sent to a chat-only model.

Responses API

/v1/responses is OpenAI's newer, alternative shape for text generation — the same underlying capability as chat completions, with a different request/response envelope: an input field instead of messages[], and an output[] array instead of choices[].

response = client.responses.create(
    model="gpt-4o",
    input="Tell me a three-sentence bedtime story about a unicorn."
)

print(response.output_text)

Streaming works the same way as chat completions — pass stream=True and consume the returned event stream.

Provider Support

Only OpenAI-native providers speak the Responses API's wire format: OpenAI, Azure OpenAI, and Custom OpenAI-Compatible connections. Routing a Responses request to any other provider (Anthropic, Google Vertex/Gemini, AWS Bedrock, a self-hosted engine, and so on) returns HTTP 400 rather than silently falling back to a chat-shaped translation — several Responses-specific fields have no chat-completions equivalent, so a silent translation could quietly drop part of the request.

Current Scope

/v1/responses support in this release covers plain text generation, with the same quota, cost-tracking, and guardrail coverage as Chat Completions. Two things work differently for now:

• Tool calls — a Responses request that results in a function/tool call is returned to the client as-is; the gateway's automatic tool-calling loop (used with the MCP Gateway) currently runs only for Chat Completions requests.
• Structured-prompt features — Prompt Decorator, Prompt Template, Topic Guard, RAG injection, and the semantic cache's similarity match all read the standard messages[] array. Since a Responses request carries input instead, Prompt Decorator and Prompt Template currently pass such a request through unaffected, while Topic Guard, RAG, and the semantic cache fall back to scanning the request's raw text rather than parsing it message-by-message.

Pricing and Usage Metrics

The additional modalities are integrated into the existing AI Cost Settings and Reports infrastructure:

Modality	Pricing Unit	Usage Metric
STT (whisper)	Per minute	Audio duration (seconds/minutes)
TTS	Per character	Input character count
Image generation	Per image (by size)	Number of images generated
Embeddings	Per 1M input tokens	Input token count

These metrics are visible in Reports and Analytics alongside other LLM models, broken down by person/team/model.

ipucu

New models (such as whisper, TTS, and gpt-image) ship with pre-configured prices in the catalog; you can customize model pricing from the AI Cost Settings page if needed.

Endpoint Routing

The gateway automatically recognizes the target path of the incoming request (/v1/chat/completions, /v1/audio/transcriptions, /v1/audio/speech, /v1/images/generations, /v1/embeddings, /v1/responses) and routes it to the modality-specific processing pipeline (including binary response support, multipart parsing, and duration-based usage calculation) — no additional configuration is required, and all modalities can be served through the same AI Gateway.

Next Steps

AI Cost Settings

Customize pricing per modality

Reports and Analytics

Track usage and cost by modality

Advanced Guardrails

Configure guardrail layers, including PII masking on STT responses

Vector Database

See where embeddings are stored and searched
